FE-2X10W-DMOD


2x10W IP-INTEGRA Linux SIP-amplifier module developed for 4M DIN-box

• Make your own customizable IP-speaker or an IP-amplifier with Relay!

• 4M DIN-box size ready to put inside of 4M DIN cabinet

• Group Multicast and individual paging by dialing extension number

• Connect: 2 passive speakers, microphone, relay input, I/O pins, USB

• Designed to wide response for music & speech in full quality

• Easy SW setup through WEB interface & auto-provision

Category: .

FE-2X10W-DMOD is a class-D amplifier module able to connect to any SIP-server as standard SIP-client and get a phone call as standard SIP-extension.

Specification

Audio
Internal audio amplifier: 2×10 W class D
Low Noise: -90dB
Efficiency: > 90%
Audio Codecs: Mp3, PCM, G.729, G.722, GSM, A-law, u-law,
THD+N 0.1% @ PO = 5W, f = 1kHz, RL = 8Ω
Hardware
Ethernet connector: 1 x RJ 45
Power options: PoE+ IEEE 802.3at or external 12V/2A DC
Power consumption: Idle 1.8W, max 24W (depending on volume)
CPU: Allwinner H2+, Quad-core Cortex A7
Software
Web-interface: dashboard with HTTPS based configuration, alarm settings,
Sound adjustments: echo-cancel, sound mute, silence suppression, paging start/stop tone, microphone boost/mute
Scheduler: bulk adding, automatic fill-out, ring-tone upload
Remote-provisioning: automatic synchronizing of SIP-server scheduler and sound files; device discovery
Logging: Call, event and scheduler logs

Construction
Dimension: 71x58x90 (suitable for DIN box size 4M)


Environment
Operation temperature: -20°C to 70°C
Storage temperature: -40°C to 70°C
Humidity: 10% to 95%, no dew
I/O
Speaker Output: 4-8Ω, 10 W
Line-out: 600Ω, 2Vpp
Relay: 1 x 30VDC – DTMF and XML controlled
Output: 3 Open-Collector, 2A, up to 15V
Input: optional for 2 switch buttons, ground activated
Mic: plug for a condenser microphone
General I/O: USB, RS485
Networking and Protocols
Protocols: IPv4, SIP, TCP, UDP, HTTP, RTP, DHCP, NTP
LAN protocols: PoE (IEEE 802.3at) Network Access Control (IEEE 802.1x)
Management and operation: HTTP (Web configuration) DHCP and static IP, Remote software upgrade & monitoring.
SIP support: RFC 3261 (SIP base standard) RFC 3515 (SIP refer) RFC 2976 (SIP info), RFC 5630 SIPS URI scheme
DTMF support: RFC 2833, 2976 (SIP info)
